| Product | Film | |
| Pattern | Production Process | Reprint |
| Minimum Line/space | 15μm / 30μm | |
| Feature Accuracy | ±10μm | |
| Coating | Photosensitive ink | |
| Optical Density OD | 2(Transmittance=1%) | |
| Reflectivity | 6% | |
| Color Selection | Black | |
| Film Base | Application | Reflective and Transmissive illumination applications |
| Expansion Coeff | 18μm/℃ of 1m | |
| The film contract with heat and expand with cold. | ||
| When the relative humidity is constant, the film with a length of 1m will change by 18μm when the temperature changes by 1℃. | ||
| Transmission (400~700nm) |
>50% | |
| Film Base Thickness | 0.1±0.01mm) | |
| MAX Size | 1.8x1.2m (±0.1mm) (Min Line 15μm) | |
| Waterproof | Waterproof | |
| Overall Shape | Straight Edge Cutting / Round Hole Hollowing by Laser Cutting | |
