| Max Sensor Size (φmm) | 2/3" | ||||
| Image Circle (φmm) | 7.07 | ||||
| Imaging | One-shot Outer Wall Inspection | ||||
| Compatible with FA Lens Focal Length | 16mm | ||||
| Mount | C | ||||
| Wavelength (mm) | 450~640 | ||||
| Object Diameter (mm) | 5~30 | ||||
| Object Diameter |
Max.Objet Height Inspection |
Working Distance |
Imaging |
| 5mm | 3mm | 41mm | Outer Wall Imaging Only |
| 7mm | 5mm | 39mm |
Simultaneous Outer Wall and Top Imaging |
| 10mm | 6mm | 36mm | Simultaneous Outer Wall and Top Imaging |
| 15mm | 11mm | 30mm | Simultaneous Outer Wall and Top Imaging |
| 20mm | 13mm | 24mm | Simultaneous Outer Wall and Top Imaging |
| 25mm | 18mm | 15mm | Simultaneous Outer Wall and Top Imaging |
| 30mm | 18mm | 10mm | Outer Wall Imaging Only |
